ERICBATTERYCHARGEROnboardChargerRepairs
15
ONBOARDCHARGERREPAIRS
WARNING
•Knowledgeofbatterychargerwiringandcomponentterminologyisrequiredbeforeattemptingany
repair(Figure15-7,Page15-11).
•Priortoservicingthecharger,disconnecttheDCplugfromthevehiclechargerreceptacleandthe
ACcordfromtheACoutlet.
NOTE:Theonboardchargerisavailableonfour-passengervehiclesandislocatedontheundersideoftherear-facing
seat.
Thischargerhasnointernalstoserviceorrepair.Itonlyhasafewexternalrepairsthatcanbeperformed.
Ifaninternalcomponentneedsrepair,thechargermustbereplaced.
6
10
7
5
8
9
12
11
13
4
21
3
2792
Figure15-12OnboardHigh-FrequencyChargerMounting
ONBOARDCHARGERREMOVAL
1.Ifconnected,disconnectACcord(1)fromACoutlet(Figure15-12,Page15-27).
2.Disconnectthebatteriesanddischargethecontroller.SeeDisconnectingtheBatteries–ElectricVehicles
onpage1-4.
3.Liftrear-facingseatbottom(2)andsupportintheraisedposition.
2018OnwardMaintenanceandServiceManualPage15-27
