Club Car Onward 2018 Service Manual

ELECTRICALCOMPONENTS–SUBARUEX40Starter/Generator
19
7
2
2
5
4
3
1
6
7
495
Figure19-9FieldCoilAssembly
COMMUTATORCLEANINGANDINSPECTION
1.Cleanthecarbondust,dirtandoilfromthecommutator.Visuallyinspectthecommutatorforworn,burnedor
glazedareas.Checkforlooseorraisedcommutatorbars.Slightroughnessofthecommutatorcanbepolished
awaywith400grit(orner)sandpaper.SeefollowingCAUTION.
CAUTION
•Donotuseemeryclothonthecommutator.Particlesofemeryareconductiveandmayshort-circuit
thecommutatorbars.Donotuseoilorlubricantsonthecommutatororbrushes.
2.Usingamicrometer,measuretheoutsidediameterattwopointsalongthecommutator.Ifthecommutatoroutside
diameterislessthan1.535inches(39mm),replacethearmatureandbearings(Figure19-10,Page19-8).
2018OnwardMaintenanceandServiceManualPage19-7
