FUELSYSTEM–SUBARUEX40EngineControlLinkages
21
ENGINERPMADJUSTMENT
DANGER
•Donotoperategasolinevehicleinanenclosedareawithoutproperventilation.Theengineproduces
carbonmonoxide,whichisanodorless,deadlypoison.
1.Ifgovernorisadjusted,proceedtostep2;otherwise,adjustgovernor.SeeGovernorCableInstallationand
Adjustmentonpage21-7.
2.Connectbatteryandsparkplugwire(s).
SeeConnectingtheBattery-GasolineVehiclesonpage1-3.
3.Measurevehiclegroundspeed.SeeHowtoMeasureGroundSpeedonpage21-10.
4.ComparemeasuredgroundspeedwithforwardgroundspeedspeciedinSection2–VehicleSpecications.
5.Ifadjustmentisnecessary,usethefollowingprocedures:
5.1.ToreduceRPM,adjustthetwojamnuts(9)tomovetheacceleratorcablehousingtowardtherearof
thevehicleuntilspeciedgroundspeedisreached(Figure5-4,Page5-5).SeeSection2–Vehicle
Speciîš¿cations.
5.2.ToincreaseRPM,adjustthetwojamnutstomovetheacceleratorcablehousingforwarduntilspeciîš¿ed
groundspeedisreached.
5.3.Besurebothjamnutsarelockedagainsttheunderbodyandcheckgroundspeedagain.Ifgroundspeed
needstobeadjusted,repeatpreviousstep.SeefollowingNOTE.
NOTE:Ifmoreadjustmentisrequiredthanthecablehousingwillallow,makesurethespringîš¿ttingontheotherend
oftheacceleratorcableisproperlyinstalled.Excessivedrivebeltandclutchwearcanalsopreventproper
groundspeedadjustment.Checkthemforexcessivewear.Section23—Clutches–SubaruEX40
2018OnwardMaintenanceandServiceManualPage21-11
