Club Car Onward 2018 Service Manual

15
OnboardChargerRepairsERICBATTERYCHARGER
3.Liftrear-facingseatbottomandsupportintheraisedposition.
4.DisconnectDCchargingharnessfromonboardchargerDCcord.
5.Disconnect14-pinplugfromonboardcharger.
6.Removeaccesspanelandelectronicsmodulecover.SeeElectronicsModuleCoverRemoval,Section13,
Page13-6.
7.Disconnectbluewirefrommainwireharnessatbulletconnector.
8.Disconnect10-gaugeblackwirefromcontrollerB-terminal.
9.Disconnect10-gaugeredwirefromsolenoid.
DCCHARGINGHARNESSINSTALLATION
1.Connect10-gaugeredwiretosolenoid.Tightennut72to84lb·in(8to9.5N·m).
2.Connect10-gaugeblackwiretocontrollerB-terminal.Tightenboltto108lb·in(12.2N·m).
3.Connectbluewiretomainwireharnessatbulletconnectorwithlightbluewire.
4.Installelectronicsmodulecoverandaccesspanel.SeeElectronicsModuleCoverInstallation,Section13,
Page13-6.SeefollowingNOTE.
NOTE:RouteDCchargingharnessthroughnotchinaccesspanel.
5.Connect14-pinplugtoonboardcharger.
6.ConnectDCchargingharnesstoonboardchargerDCcord.
7.Lowerrear-facingseatbottom.
8.PlacetheTow/RunswitchintheTOWpositionandconnectthebatteries.SeeConnectingtheBatteries–
ElectricVehiclesonpage1-4.
Page15-302018OnwardMaintenanceandServiceManual
