ELECTRICALCOMPONENTS:ELECTRIC
VEHICLEReverseBuzzer
13
REVERSEBUZZER
SeeGeneralWarningsonpage1-2.
TESTINGTHEREVERSEBUZZER
See12-37.
REVERSEBUZZERREMOVAL
1.Disconnectthebatteriesanddischargethecontroller.SeeDisconnectingtheBatteries–ElectricVehicles
onpage1-4.
2.Removeinstrumentpanel.SeeKeySwitchRemovalonpage13-1.
3.Disconnectthe18-gaugepinkandorange/whitewiresfromreversebuzzer.
4.Removethetwoscrewsfromthereversebuzzer.Removethereversebuzzerfromthedashpanel.
REVERSEBUZZERINSTALLATION
1.Installthereversebuzzerinthereverseorderofremoval.Pinkwiremustbeconnectedtothepositiveterminal.
Tightenscrewsto4lb·in(0.45N·m).
2.PlacetheTow/RunswitchintheTOWpositionandconnectthebatteries.SeeConnectingtheBatteries–
ElectricVehiclesonpage1-4.
3
2
1
4
(Viewedfromundersideofinstrumentpanel)
A.PinkB.Orange/White
711
Figure13-10ReverseBuzzer
2018OnwardMaintenanceandServiceManualPage13-9
