ELECTRICALCOMPONENTS:ELECTRIC
VEHICLESolenoid
13
5.PlacetheTow/RunswitchintheTOWpositionandconnectthebatteries.SeeConnectingtheBatteries–
ElectricVehiclesonpage1-4.
6.PlacetheT ow/RunswitchintheRUNposition.
7.IfvehicleisequippedwiththeGuardianSVCsystem,performthefollowingadditionalstepsforpropersetup.
7.1.ConnectanCDTtotheCDTportonthevehicle.
7.2.SelectProgram,Settings,ControlModeandsetthevalueto1.
7.3.SelectProgram,Settings,AntiTamperandsetthevalueto0.
7.4.SelectProgram,VehicleID,VehicleS/Nandenterthelastsixdigitsofthevehicleserialnumber.
NOTE:Thespeedforscrollingvaluesmaybeincreasedbyutilizingthebookmarkkeys(yellowbuttons)incombination
withthedatainc/deckey(+/-).
7.5.SelectProgram,VehicleID,VehicleDecalandenterthenumberontheVehicleNumberDecal.
7.6.SelectProgram,VehicleID,VehicleDateofManufactureandenterthenumberonthemodelyearand
weekfromthevehicleserialnumber.
7.7.SelectInformation,SoftwareVersionandverifythevalueis13orhigher.Ifnot,contactaClubCar
TechnicalRepresentative.
7.8.PlacetheT ow/RunswitchintheTOWpositionfor30seconds.ThenreturnittoRUN.
8.Inspectthevehicleforproperoperation.
WARNING
•MakesurethatthevehicleoperatesintheforwarddirectionwhentheForward/Reverseswitchis
intheFORWARDposition.
•MakesurethatthevehicleoperatesinthereversedirectionwhentheForward/Reverseswitchisinthe
REVERSEposition.ThereversebuzzerwillsoundasawarningwhentheForward/Reverseswitch
isinREVERSE.
•MakesurethatthevehicledoesnotoperatewhentheForward/ReverseswitchisintheNEUTRAL
position.
SOLENOID
SeeGeneralWarningsonpage1-2.
Thesolenoidislocatedontherearsideoftheelectronicsmodule.
TESTINGTHESOLENOID
SeeTestProcedure7–SolenoidActivatingCoilonpage12-27andTestProcedure9–SolenoidContinuityon
page12-28.
SOLENOIDREMOVAL
1.Disconnectthebatteriesanddischargethecontroller(1).SeeDisconnectingtheBatteries–ElectricVehicles
onpage1-4.
2.Removetheelectronicsmodulecover(8)toaccessthesolenoid(4).SeeElectronicsModuleCoverRemoval
onpage13-6.
2018OnwardMaintenanceandServiceManualPage13-13
