ERICBATTERYCHARGERChargerTroubleshooting

EXTERNALCHARGERTROUBLESHOOTINGINDICATORS

Ifafaultoccurs,countthenumberofredashes(onthechargerordash)betweenpausesandrefertothetablebelow:

EXTERNALCHARGERTROUBLESHOOTINGGUIDE

CHECKSTATUS

INDICATORLIGHT

STATUS

EXPLANATION

POSSIBLECAUSES

(checkinordershown)

SOLUTIONS

1.ACcordconnection

UnplugandinspectACcord.Reconnectand

attempttochargeagain.

2.ACpowersupply

wasshutoff

VerifyACpowerispresentandchargeagain.SeeAC

PowerandContinuityTestofACCircuitonpage15-22.

3.ACcircuitbreaker

istripped

ResetACcircuitbreakerandchargeagain.

4.ImproperACoutlet

voltage

TestACoutletvoltageandcorrectifnecessary.SeeAC

PowerandContinuityTestofACCircuitonpage15-22.

OFF

ACpowerto

chargerisNOT

present.

5.FailedACplugorcord

Replacecord.SeeACPowerandContinuityTest

ofACCircuitonpage15-22.

TABLECONTINUEDONNEXTPAGE
