ENGINE–SUBARUEX40GeneralInformation
20
VALVECLEARANCECHECKANDADJUSTMENT
NOTE:Checkandadjustclearancewhentheengineiscold.
1.Ifequipped,removeairdeectorfromtopofengine.
2.Removerockercover.
3.Turnthecrankshaftuntilthepistonisattopdeadcenterofthecompressionstroke(Figure20-5,Page20-7).
4.Usingafeelergauge(1),measuretheclearancebetweentheadjusterscrew(3)andthetopofthevalvestem
(Figure20-6,Page20-7).
5.Ifnecessary,loosenthelocknut(2)andturntheadjuster(3)upordowntoadjusttheclearanceto0.0047in.
(0.12mm)forbothintakeandexhaust.Onceclearanceiscorrect,tightenthelocknut(2)to52lb·in(6N·m).
6.Afteradjustingvalveclearances,rotatethecrankshaftseveralfullrevolutionsandverifythattheintakeand
exhaustvalveclearancearestillcorrect.
AtTDC,thetwopunchmarksoncamsprocketareparallelwiththe
cylinderheadsurface.
1
2
4
3
5
1.FeelerGauge2.LockNut3.AdjusterScrew4.RockerArm
(exhaust)5.RockerArm(intake)
3034
Figure20-5TopDeadCenter(TDC)–EX40Engine
3035
Figure20-6SettingValveClearance–EX40Engine
2018OnwardMaintenanceandServiceManualPage20-7
