4 – Operation
BodyGuard 595™Color Vision Operator Manual
29
MicroSet™ with 0.2mic Filter
Area
Function
1.
Spike Cap
Keeps the set sterile
2.
Spike
Connects the administration set to
solution bag
3.
Administration Tubing 1.5 x 3 mm
Transfers the solution
4.
Anti Stretch locator
Prevents incorrect tube stretching
and locates the administration set
correctly
5.
Administration Tubing 3 x 4.1 mm
Soft segment of the set for increased
delivery accuracy
6.
Key
Locates the tube in the correct flow
direction
7.
Filter 0.2 micron
Filters the fluid path from air and
particles
8.
Slide clamp
Can be used to occlude the tube
9.
BodyValve™ With Cap
Connects the administration set to the
patient access device – prevent free
flow
Loading the Administration Set

NOTE: follow the instructions supplied with the individual administration set.
Warning: use of any administration set, other than the MicroSet
TM
, may impair
the operation of the pump and the accuracy of the Infusion.
9
8
7
6
5
4
3
2
1
