5 – Alarm Conditions and Troubleshooting
BodyGuard 595™Color Vision Operator Manual
63
Troubleshooting
Description
Result
Possible Cause
Required Action
Infusion stops
and an alarm is
activated
Air is present in administration
Set.
The roller or clip on the
administration set is closed
upstream of the pump.
The line was not loaded correctly.
Disconnect line from patient, press
key. Pump stopped screen is
displayed. Press & hold (3sec) on the
key, then select Prime option.
Follow the steps in "Priming a set"
section.
Re-load the administration line.
Infusion stops
and an alarm is
activated
The roller or clip on the
administration set is closed
downstream of the pump.
Administration set is kinked.
Cannula is blocked.
Administration set loaded
incorrectly.
NOTE: operator may change
pressure setting.
Open clamp/clip.
Straighten the set.
Change the Cannula.
Re-load the administration line.
Refer to “Down Occlusion Alarm”
section.
An alarm is
activated
Two minutes has elapsed without
a button press during
programming.
Press to resume.
Infusion stops
and an alarm is
activated
The door of the pump was not
closed prior to operation
The door has accidentally opened
during operation.
Close the door of the pump.
Send the pump for service.
Pump will only
run for another
30 minutes if it is
not connected to
mains.
30 Minutes of battery life are
remaining.
Place the pump in charger and
connect to mains.
PCA 10:00 - 70% █ ■
Air or Up
Occlusion
Check for air / Occlusion
Press key to mute
PCA 10:00 - 70% █ ■
Down
Occlusion
Check Set / Access
Press key to mute
PCA 10:00 - 70% █ ■
Pump Paused
Too Long
Press key
PCA 10:00 - 70% █ ■
Door Open
Close door
PCA 10:00 - 10% █ ■
Low Battery
Connect to Charger
