BodyGuard 595™Color Vision Operator Manual
Protocol
The currently selected protocol letter (A-Z) appears in the left hand margin of the
display. Protocol or drug name appears on the top line of the display. This is useful as
you may use a standard morphine solution of, say, 1mg/ml, but have up to 26 protocols
using different bolus volumes and lockouts.
Air Sensor
Air sensor enable/disable indication. This line appears only if the sensor is disabled.
When sensor enable no message will appear.
Infusion Rate
The third line of the display shows the current infusion rate. Depending on whether the
user programmed the current protocol in ml/mg/mcg, this will display the rate in either
ml/h, mg/h or mcg/h.
Bolus Volume, Lockout Time and Interval
Displayed information may include boluses volume, lockout time and interval for the
current protocol. As with infusion rate, bolus dose will be displayed in ml, mg or mcg
depending on how the current program is set up. User will be able to select type of
boluses: auto bolus, patient bolus, or a combination of auto and patient boluses.
Battery Status
In the right hand margin, you can see the battery and infusion status indicator. The
battery symbol will be visible when the pump is not connected to the mains charger.
User can check the charge level by monitoring the black fill inside the symbol (i.e.
completely black symbol indicates a fully charged battery).
Actual Pressure
The bar displays real time in-line pressure. Units of measure, start value, and peak
value are subject to the pump pressure settings (See change set-up menu). The bar is
divided to 3 parts. Actual pressure is displayed as red fill. When the pressure rises from
one segment to the next a beep will sound. If the pressure reaches the end value
(400mmHg in the above example) the pressure alarm will sound.
MediGuard
TM
Option
MediGuard
TM
option enables the medical staff to control the maximal rate of drugs
approved to a specific patient based on the patient’s weight.
To enable this option, enter “Change Set Up” option on menu and scroll to "Program
Limits". Press to access and set MediGuard
TM
On. Press key to approve.
When MediGuard
TM
option is on, the user will be required to set the maximal approved
MediGuard
TM
rate. Maximal MediGuard
TM
rate will be defined as ml (mg,
microgram)/hour per 1 kg. of patient weight
When selecting a protocol, either by 'Select Protocol' or by 'Modify Protocol Library', the
user will be required to set the patient weight in kg. The software will calculate the
maximal rate allowed for the specific patient based on his weight (multiplied by the
maximal MediGuard
TM
rate). The calculated values will be displayed as “Drug Limit” in
