System block diagrams
98-127093-H Chapter 2: Introduction to the AVIATOR 200/300/350 2-19
2222
2.3.6 User interfaces
The AVIATOR 200/300/350 system has the following user interfaces:
Table 2-12: AVIATOR 200/300/350 user interfaces
Interfaces Number
2-wire POTS interface
This interface can be used for the TT-5621B 2-Wire Handset and TT-
5622B 2-Wire Cradle or other POTS handsets. The TT-5622B 2-Wire
Cradle has an RJ11 connector to which additional 2-wire terminals can be
connected, e.g. for fax or modem data.
2
10/100BaseT Ethernet interfaces for connecting IP equipment.
Note that the SBU has a Built-in Router option. The SBU has an additional
Ethernet interf
ace for system configuration (Maintenance connector on
the SBU front plate, not shown in the following figure).
6
Built-in Wireless Option with two WLAN antenna interfaces for diversity
operation to connect WiFi-enabled equipment like lap tops, PDAs or VOIP
handsets.
1
(32 devices)
Euro ISDN S-bus interface for PC, Fax or STE (without DC power support)
a
a. Note that the ISDN data service (UDI/RDI) cannot be used by the AVIATOR 200 nor the
AVIATOR 200D.
1
Discrete outputs for annunciators 4
The following figure shows most of the possible user interfaces.
Figure 2-7: AVIATOR 200/300/350 interfaces
Note that the ISDN data service (UDI/RDI) cannot be used by the AVIATOR 200 nor the
AVIATOR 200D.
77$6%8
,3(TXLSPHQW
,6'1
(WKHUQHW
$QQXQFLDWRUV
'LVFUHWH
2XWSXWV
*)D[
:&UDGOH :+DQGVHW
,3GHYLFH
,3GHYLFH
,3GHYLFH
:/$1DQWHQQD
:LUHOHVV,3
HTXLSPHQW
GHYLFHV
ZLUH
5-
:/$1
,6'1SKRQH
*)D[
3&5RXWHU
9LGHRSKRQH
SB-Lite.book Page 19 Tuesday, September 5, 2017 1:38 PM
