COBHAM D-MBR 3707 User Manual

D-MBR 3707-3708 PS NFPA CLASS A SIGNAL BOOSTER
PRODUCT DESCRIPTION AND USER’S MANUAL
Cobham Wireless – Coverage
Date: 17-Jan-16
www.cobham.com/wireless
Doc. No.00060CDUM Rev. 1.1 Page | 31
4.4 Charger Installation Procedure
WARNINGS!
• Be sure the external battery meets the following requirements:
Valve-Regulated Lead-Acid (VRLA)
Gelled Electrolyte (gel) and Absorbed Glass Mat (AGM) Batteries or LEAD ACID
• Be sure the booster is connected to the Charger (providing a load) BEFORE AC feed or
the Battery is connected to the charger.
• BEFORE POWERING THE SYSTEM on, make sure
• CHARGER DC OUT is connected to BOOSTER DC IN
• BATTERY connection at CHARGER is connected to EXTERNAL
BATTERY
• When connecting or disconnecting the battery, ALWAYS recycle AC power to the
Battery Charger.
The Charger installation procedure consists of the following steps.
Figure 4-4 Physical Installation Workflow
Step-1
• Installation Location
Step-2
• Unpacking
Step-3
• Mounting
Step-4
• Grounding
Step-5
• Alarm connections
Step-6
• Connection to Repeater
Step-7
• Connection to Battery
Step-8
• Connection to AC Feed
