4.4.3 Charger Mounting Procedure
The charger is mounted next to the Booster and the mounting instructions are identical to that of the
Booster.
Refer to section 3.3 for mounting instructions.
4.4.4 Charger Grounding
The grounding procedure is identical to the Booster grounding procedure. Refer to section 3.4.1 for
the grounding instructions.
Figure 4-5 Battery Charger GND Lug
GND LUG
