D-MBR 3707-3708 PS NFPA CLASS A SIGNAL BOOSTER
PRODUCT DESCRIPTION AND USER’S MANUAL
Cobham Wireless – Coverage
Date: 17-Jan-16
www.cobham.com/wireless
Doc. No.00060CDUM Rev. 1.1 Page | 59
6.3.4 Uploading Band Configuration File
To upload configuration file to Booster
1. In the left pane, click the 700-800 item and then click the Backup/Restore tab.
Figure 6-8. Upload Configuration File
2. Click the Upload button.
3. Select the file from the Browse dialog and click Open.
4. The file will be listed in the Backup/Restore table.
6.3.5 Saving Configuration File to Computer
To save a configuration file from the list to a selected location
1. In the left pane, click the 700-800 item and then click the Backup/Restore tab.
Figure 6-9. Save File in a Different Location
2. Select file from list.
3. Click the link in the File column.
4. Select the location in the Browse dialog
To Next Page
