6.2.2 Viewing Band Level Info
This Band Info tab displays general identification information such as build version, valid filter
definitions and more.
To access the Booster Information window
1. From the left pane, select the 700-800 item.
2. Select the Band Info tab. The relevant parameters are displayed. This includes:
• Build Version
• Filters types and relevant bandwidth – this information is relevant when defining the
RF parameters and sub-bands for each band.
Figure 6-4. Band Level Information
