Chapter 3: Operation
98-148232-E To access the terminal from a remote location 30
WANMODE: Get or set the WAN connection mode
For information on the different WAN modes, see Select network (Mode) on page 62 and
<wanmode> on page 130.
The text in the WANMODE SMS must have the following format:
WANMODE
<cmd_op> {<wanmode>} <rsms_pwd>
Example: To set the connection mode to Cellular modem preferred, send an SMS with the
text:
WANMODE 2 4 remote
In this example, the WAN connection mode is set up as follows:
2: Set WANMODE parameters.
4: Select Cellular modem preferred.
Response:
You receive a response with the result of the action.
Example: The response to the command in the example above would be:
WANMODE=4
ATCO: Send AT commands to the EXPLORER 540
The text in the ATCO SMS must have the following format:
ATCO <resp_mode> <rsms_pwd> <at_cmd>
Example: To command the EXPLORER 540 to download new software from the default FTP
server via the default APN and upgrade to the new version immediately, send an
SMS with the text:
ATCO 2 remote _IGETFW=1
Response:
You receive a response with the result of the action. In this example we have chosen to see
only the final response (<resp_mode> = 2) and we have chosen immediate upgrade
(<mode> =1), so the final (and only) response will be related to the upgrade of the
EXPLORER 540.
Example: For a successful completion of the command in the above example, the response
would then be: _IUPDFW: 0, Complete
See also ATCO response codes on page 135.
List of supported ATCO commands:
The following AT commands are supported using the ATCO command in an SMS. For syntax
and parameters, see ATCO commands on page 133.
• _IGETFW Get new firmware (and optionally install it).
See Remote software upgrade on page 42.
Note
If you are going to select Cellular modem preferred (PRISM) mode (WANMODE
6), you must first set up all parameters in the web interface. See To set up PRISM on
page 65.
