C002332_02_CR3 User Manual - 26
Save Settings
Far Field (FF): The farthest field of the CR3’s two image fields. The Far Field has the lowest resolution
(480 x 320 DPI). It has an optimal focal point of 9” (228.6 mm) away from the lens of the reader. Ithas
a size of 4” wide (101.6 mm) at the optimal focal point.
The following tables provide the ability to program all or individual triggers to perform with different
parameters.
2.2 - Global Trigger Optimization Matrix
DOT
