3.3.2. Group manage
1) Press [Group] to entry “Group Program”;
2) Press [Group manage];
3) Select the group you want to edit. It will list all the fixtures in the selected group;
4) You will find the fixture order as when you selected them.
Fixture order 1 to 5 is not exactly the same as order 5 to 1. The order is important when
applying effects and overlap functions which will be distributed along the order.
Users are allowed to change the fixture order in the group. So that the fixtures will run in the
order when use this group again.
Select ① [Fixture Order] and call out the “Fixture order setup” window;
Set the step number by soft② -key [Previous Step] or [Next Step];
Select one or more Fixtures for the step number; Please note that③ the big RED numbers on
fixtures soft-key indicate the running order, while the right bottom WHITE numbers indicate
the fixtures unit numbers;
①
②
②
③
④
④
