1.1.7. Selection keys
The part includes
options of Group, Fixture,
Preset, Effect and Macro
together with page switch
keys. Each kind of option
has 20 pages, and 20 keys
for each page.
1.1.8. Control Wheels
Control wheels A, B and C are used for setting attributes of the fixtures or the parameters
of movement effect.
Wheel D takes with a key which use for setting control values of options, and setting
Cue-lists velocity. The key in wheel D can be used as Enter or save key when setting options.
1.1.9. Touch Screen
There is a 7” TFT-LCD touch screen offers soft-keys for operating. Such as selecting
fixtures, groups, presets and menu options.
