ComAp InteliDrive Lite

ID-FLX Lite & Telecom Global Guide
69
Functions 3 and 4 setpoints
Regulator Values
LAI SpeedRequest
OFF
CU: AI1-AI9
AIO: AI1-AI4
Reg Input
CU: AI1-AI9
AIO: AI1-AI4
RPM-BI3
Reg Bias 0 - 10000
Request1 ±10000
Request2 ±10000
Reg Gain ±0.0 - 200.0 %
Reg Integral +0.0 % - 100.0 %
Reg CMP Input
CU: AI1-AI9
AIO: AI1-AI4
RPM-BI3
Reg CMP Off ±10000 [- ]
Reg CMP On ±10000 [- ]
Note: For more information see Setpoints on page 91.
Functions 3 and 4 examples
Pressure by RPM control via J1939
Pressure by RPM control via analog output
