ComAp InteliLite AMF25 User Manual

InteliLite Global Guide
180
Setpoint group Basic settings Related FW 1.9.0
Range [units] 0,1 .. 500,0 [V/V]
Default value 1,0 V/V Alternative config NO
Step 0,1 V/V
Comm object 9579 Related applications AMF, MRS
Config level Advanced
Setpoint visibility Always
Description
Generator voltage potential transformers ratio. If no PTs are used, adjust the setpoint to 1.
PT Ratio
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.9.0
Range [units] 0,1 .. 500,0 [V/V]
Default value 1,0 V/V Alternative config NO
Step 0,1 V/V
Comm object 9580 Related applications AMF
Config level Advanced
Setpoint visibility Conditioned by the setpoint Operation Mode (page 183)
Description
Mains voltage potential transformers ratio. If no PTs are used, adjust the setpoint to 1.
Vm PT Ratio
6 back to List of setpoints
Subgroup: Frequency settings
Setpoint group Basic settings Related FW 1.9.0
Range [units] 45 .. 65 [Hz]
Default value 50 Hz Alternative config YES
Step 1 Hz
Comm object 8278 Related applications AMF, MRS
Config level Standard
Setpoint visibility Always
Description
Nominal system frequency (usually 50 or 60 Hz).
Note: To lock this setpoint against editing you also have to lock setpoint Nominal Frequency 1 (page
331), Nominal Frequency 2 (page 335) and Nominal Frequency 3 (page 339).
Nominal Frequency
6 back to List of setpoints

ComAp InteliLite AMF25 Specifications

General

Inputs	8 binary inputs
Outputs	8 binary outputs
Power Supply	8-36 V DC
Communication	RS232, RS485
Operating Temperature	-20°C to +70°C
Supported Generators	Diesel, gas
Controller Type	Automatic Mains Failure Controller
Protection	IP65
