Table for HW versions 1.1 and lower.
0 - 22 mA
mA 0 1 2 3 4 5 6 7 8 9 10 11
Ω 100 131 164 200 238 280 325 374 427 485 550 621
mA 12 13 14 15 16 17 18 19 20 21 22
Ω 700 788 887 1000 1128 1276 1450 1654 1900 2200 2575
Table for HW versions 1.2 and higher.
0 - 22 mA
mA 0 1 2 3 4 5 6 7 8 9 10 11
Ω 100 110 120 130 141 154 168 182 198 216 235 256
mA 12 13 14 15 16 17 18 19 20 21 22
Ω 280 306 336 370 409 453 505 566 640 730 842
Note: This is a conversion of current from current sensor to appropriate resistance value. Use resistance
values in InteliConfig to create your specific curve. These values should be used in "Ohm" column.
Analog as binary or tristate inputs
Analog inputs can be used also as binary or tri-state, i.e. for contact sensors without or with circuit check. The
threshold level is 750 Ω. In the case of tri-state, values lower than 10 Ω and values over 2400 Ω are evaluated as
sensor failure (short or open circuit).
Image 4.35 Analog inputs as tristate Image 4.36 Analog inputs as binary
Note: The name, sensor characteristic and alarm types for each analog input have to be assigned during
configuration.
Note: Tristate and binary sensors are not suitable for Analog Switch functions.
