InteliLite Global Guide
18
2.6.4 Inteli AIO9/1
9 Analog Inputs and 1 Analog Output Module
4× differential voltage inputs for measurement in
range of 0 - 65 V or -65 V – 0 V
4× shielded, galvanically separated ±75 mV
inputs
Resistance analog input 0 – 2500 ohm
One analog output
2.6.5 IGS-PTM
The unit offers the user the flexibility to configure the unit to have 8 binary inputs, 8 binary outputs, 4 analog
inputs and 1 analog outputs.
Configurable 8 binary and 4 analog inputs
Configurable 8 binary and 1 analog output
LEDs indicate the state of binary inputs/outputs
Measures values from Pt100 and Ni100 sensors
Analog inputs (resistance range 0-250 Ohms,
voltage range 0-100mV, current range 0-20mA -
selectable via jumper)
UL certified
