InteliLite Global Guide
676
6 back to List of alarms level 2
Alarm Type Shutdown
Alarmlist message Sd GCB Fail
Alarm evaluated All the time
Related applications AMF, MRS
Description
This alarm will occur when the GCB FEEDBACK (PAGE 530) input does not match
the expected position given by the GCB CLOSE/OPEN (PAGE 574) output. It stays
active until the mismatch between the output and feedback persists.
If there was no command issued by the controller and the breaker
(feedback) changes suddenly the position itself, the alarm will be issued
immediately.
The alarm will be also issued if the breaker does not respond to an open or
close command within 2 seconds.
Sd GCB Fail
6 back to List of alarms level 2
Alarm Type Shutdown
Alarmlist message Sd Generator L1 > Voltage
Alarm evaluated Generator excited only
Related applications AMF, MRS
Description
This alarm evaluates the generator phase voltage in phase 1. The following
setpoints are related to it:
Generator Overvoltage Sd (page 230)
Generator <> Voltage Delay (page 232)
Sd Generator L1 > Voltage
6 back to List of alarms level 2
Alarm Type Shutdown
Alarmlist message Sd Generator L1 < Voltage
Alarm evaluated Generator excited only
Related applications AMF, MRS
Description
This alarm evaluates the generator phase voltage in phases 1. The following
setpoints are related to it:
Generator Undervoltage BOC (page 231)
Generator <> Voltage Delay (page 232)
Sd Generator L1 < Voltage
6 back to List of alarms level 2
