InteliMains 210 Global Guide
528
Related applications MCB, MGCB, BTB
Description
This alarm evaluates the Bus Left voltage between phases L2 a L3. The following
setpoints are related to it:
Bus Left Overvoltage (page 188)
Bus Left < > Voltage Delay (page 189)
Note: Alarm is active only in case the setpoint Connection type (page 176) is
set to 3Ph3Wire or High Leg D.
6 back to List of alarms level 2
Alarm Type Breaker open
Alarmlist message No
Alarm evaluated All the time
Related applications MCB, MGCB, BTB
Description
This alarm evaluates the Bus Left voltage between phases L2 a L3. The following
setpoints are related to it:
Bus Left Undervoltage (page 188)
Bus Left < > Voltage Delay (page 189)
Note: Alarm is active only in case the setpoint Connection type (page 176) is
set to 3Ph3Wire or High Leg D.
Bus Left L2L3 Undervoltage
6 back to List of alarms level 2
Alarm Type Breaker open
Alarmlist message No
Alarm evaluated All the time
Related applications MCB, MGCB, BTB
Description
This alarm evaluates the Bus Left phase voltage in phases. The following setpoints
are related to it:
Bus Left Overvoltage (page 188)
Bus Left < > Voltage Delay (page 189)
Note: Alarm is active only in case the setpoint Connection type (page 176) is
set to 3Ph4Wire.
Bus Left L3 Overvoltage
6 back to List of alarms level 2
Alarm Type Breaker open
Alarmlist message No
Alarm evaluated All the time
Bus Left L3 Undervoltage
