CONNECTION TERMINALS
Terminal Function
- Bus power supply negative
+ + 24 Vdc bus power supply
FAIL
NC contact
(power supply failure indication)
Earth
L Power supply phase (230 Vac)
N Power supply neutral (230 Vac)
Earth terminal connection may cause disturbance on the communication
bus
