2.10 - ART. 20046606 - SIMPLEHOME MODULE WITH 9 OPTICALLY COUPLED INPUTS
AND 8 X 16A RELAY OUTPUTS ON DIN RAIL (9I8O16A)
Module on bus has 8 inputs + 1 scenario input, as well as 8 relay outputs with switching contact with independent common capable of controlling
resistive electrical loads up to 16A. For non-resistive loads, it is best to use a support contactor at each output.
Technical characteristics
Power supply voltage 24 Vdc ± 5%
Absorption min. 8mA, max. 220 mA
Inputs 8+1, optically coupled digital type
Outputs 8 relay 230 Vac, resistive 16A (cos
ϕ = 1)
Max. input cable length 25 m
Protection against reverse polarity
Indications
1 bus status indicator LED: when ashing, indicates data transmission via bus, when lit steadily
indicates lack of power supply negative or incorrect device connection
9 input status indicator LEDs
8 output status indicator LEDs
Lack and restoring of
power supply
output status memory
Terminals removable for BUS connection
Positioning on DIN rail or in junction boxes
Applicable standards
electromagnetic compatibility: EN 50081-1 (interference emission)
and EN50082-2 (resistance to interference)
Approvals CE
Operating temperature 0° to 50°C
Storage temperature -10° to +70°C
Relative air humidity 5 to 95% with no condensation
Weight 380 g (not including packaging)
Dimensions 160x90x58 mm (9 DIN modules)
27
