2.11 - ART. 20046810 - SIMPLEHOME MODULE WITH 2 ANALOGUE INPUTS
AND 2 ANALOGUE OUTPUTS ON DIN RAIL (2I2O)
Interface on DIN rail for SimpleHome system, with two inputs and two 0-10 V analogue outputs. Allows interfacing between the
automation system and analogue inputs, such as light sensors or voltage/current transformers, as well as the management of
electronic adjustment devices such as lighting ballasts or dimmers. It is not suitable for the connection of the temperature sensor
with 0-10 V output (20046708).
Technical characteristics
Power supply voltage 24 Vdc ± 5%
Absorption min. 5 mA, max. 30 mA
Inputs 2 analogue, 0-10 V
Maximum input cable length 5 m
Outputs 2 analogue, 0-10 V with max. current 100 mA
Protection against reverse polarity
Indications
1 bus status indicator LED: when fl ashing, indicates data transmission via bus,
when lit steadily indicates lack of power supply negative or incorrect connection
of the device
Terminals removable
Positioning on DIN rail or in junction boxes
Lack and restoring of power supply output status memory
Applicable standards
electromagnetic compatibility: EN 50081-1 (interference emission)
and EN50082-2 (resistance to interference)
Approvals CE
Operating temperature 0° to 50°C
Storage temperature -10° to +70°C
Relative air humidity 5 to 95% with no condensation
Weight 130 g (not including packaging)
Dimensions 53x90x58 mm (3 DIN modules)
