2.8 - ART. 20046604 - SIMPLEHOME MODULE WITH 5 OPTICALLY COUPLED INPUTS
AND 4 X 16A RELAY OUTPUTS ON DIN RAIL (5I4O16A)
Module on bus has 4 inputs + 1 scenario input, as well as 4 relay outputs with switching contact with independent common capable of controlling
resistive electrical loads up to 16A. For non-resistive loads, it is best to use a support contactor at each output.
Technical characteristics
Power supply voltage 24 Vdc ± 5%
Absorption min. 5 mA, max. 140 mA
Inputs 4+1, optically coupled digital type
Outputs 4 relay 230 Vac, resistive 16 A (cos
ϕ = 1)
Max. input cable length 25 m
Protection against reverse polarity
Indications
1 bus status indicator LED: when ashing, indicates data transmission via bus, when lit steadily
indicates lack of power supply negative or incorrect device connection
5 input status indicator LEDs
4 output status indicator LEDs
Lack and restoring of
power supply
Output status memory
Terminals removable for BUS connection
Positioning On DIN rail or in junction boxes
Applicable standards
electromagnetic compatibility: EN 50081-1 (interference emission)
and EN50082-2 (resistance to interference)
Approvals CE
Operating temperature 0° to 50°C
Storage temperature -10° to +70°C
Relative air humidity 5 to 95% with no condensation
Weight 195 g (not including packaging)
Dimensions 71x90x58 mm (4 DIN modules)
23
