Technical characteristics
Power supply voltage 24 Vdc ± 5%
Absorption MIN. 5 mA / MAX. 40 mA
Indications 1 bus status LED: when fl ashing, indicates data transmission via bus.
Terminals Removable
Positioning On DIN rail or in junction boxes
Approvals CE
Operating temperature 0° to 50°C
Storage temperature -10° to +70°C
Relative air humidity 5 to 95% with no condensation
Weight 50 g (not including packaging)
Dimensions 53x90x58 mm (3 DIN modules)
CONNECTION TERMINALS
Terminal Function
- BUS power supply negative
+ BUS power supply +24 Vdc
D BUS data line
DA+ DA- DALI BUS
A/L+ B/L- GND DMX BUS
Jumper J1 DALI / DMX function selector
