Compaq ProLiant 3000 Servers, for use with Intel 350 MHz or greater processor-based servers only, Maintenance and Service Guide
Spare Parts List
Table 1-1
Spare Parts List - Compaq ProLiant 3000 Servers
Ref Description Spare Part #
CHASSIS
1 Chassis 306574-001
2 Side Access Panel 298364-001
3 Access Panel Kit
a) U-Channel Access Panel
b) Top Access Panel
327835-001
4 Front Bezel Door 298360-001
5 Fixed Front Bezel (Tower Model Only) 298361-001
6 Rack-Mount Bezel Plate 298363-001
7 Locking Casters 296227-001
8 Caster Mounting Support 330485-001
SYSTEM COMPONENTS
9 Front Fans (2) 306576-001
10 Rear Fan 306577-001
11 Redundant High-Speed Fan 326873-001 *
12 Hot-Plug Power Supply, 750W 169286-002
13 Integrated Management Display with Cable 271930-001
14 Power Switch with LED 387738-001
15 4.5 V Replacement Battery 160274-001
16 Intel Pentium III Processor, 500/100 MHz (512 K ) with Heatsink 114525-001
17 Processor Power Module (Voltage Regulator) 329267-001
18 SCSI Simplex Hot-Plug Drive Cage
a) Hot-plug drive cage with Simplex board
b) Removable media panel
306572-001
BOARDS
19 Hot-Plug Power Supply Backplane Board 169290-001
20 System I/O Board with Subpan 179779-001
21 Netelligent 10/100 TX UTP PCI Controller (NIC) 317606-001
Continued
