3-19
Compaq ProLiant 3000 Servers, for use with Intel 350 MHz or greater processor-based servers only, Maintenance and Service Guide
Primary Processor Test Error Codes
The 100 series of Diagnostic error codes identifies failures with processor and system board
functions.
Table 3-2
Primary Processor Test Error Codes
Error Code Description Recommended Action
101-xx CPU test failed Replace the processor board and retest.
103-xx
104-xx
105-xx
106-xx
DMA page registers test failed.
Interrupt controller master test failed.
Port 61 error.
Keyboard controller self-test failed.
For error codes 103-xx through 106-xx, replace the
processor board and retest.
107-xx
108-xx
109-xx
CMOS RAM test failed.
CMOS interrupt test failed.
CMOS clock load data test failed.
The following steps apply to error codes 107-xx
through 109-xx:
Replace the battery/clock module and retest.
Replace the system board and retest.
110-xx
111-xx
112-xx
113-xx
Programmable timer load data test failed.
Refresh detect test failed.
Speed test slow mode out of range.
Protected mode test failed.
For error codes 110-xx through 113-xx, replace the
system board and retest.
114-xx Speaker test failed. 1. Verify the speaker connection and retest.
2. Replace the speaker and retest.
3. Replace the system board and retest.
116-xx Cache test failed. Replace the system board and retest.
122-xx
123-xx
Multiprocessor Dispatch test failed.
Interprocessor Communication test failed.
The following steps apply to error codes 122-xx
through 123-xx:
Check the system configuration and retest.
Replace the processor board and retest.
Replace the system board and retest.
199-xx Installed devices test failed. 1. Check the system configuration and retest.
2. Verify cable connections and retest.
3. Check switch and/or jumper settings and
retest.
4. Run the Configuration utility and retest.
5. Replace the processor board and retest.
6. Replace the system board and retest.
