Compaq ProLiant 3000 Servers, for use with Intel 350 MHz or greater processor-based servers only, Maintenance and Service Guide
Fans
Compaq ProLiant 3000 Servers ship standard with two 120-mm front fans (in positions 1 and 3)
and one 92-mm rear fan (in position 5).
The figure below shows the location of the front and rear fans in the ProLiant 3000 Server. You
can add two fans for redundancy in the positions marked Fan 2 and Fan 4.
IMPORTANT: Redundant fans must be added in pairs.
Fan 1
(CPU)
Fan 5
(CPU Aux)
Fan 4
(I/O Redundant)
Fan 2
(CPU Redundant)
Fan 3
(I/O)
Figure 2-11. Location of fans
