4-6 Connectors, Switches, Jumpers, and LEDs

Jumpers

The external battery jumper for ProLiant 3000 Servers is located on the system I/O board.

Figure 4-8 shows the configuration when using an internal battery

or an external battery

INT.

JUMPER

EXT.

JUMPER

Figure 4-8. Battery jumper location and default settings
