2-25
Compaq ProLiant 3000 Servers, for use with Intel 350 MHz or greater processor-based servers only, Maintenance and Service Guide
Removable Media Devices
The removable media area contains the standard CD-ROM drive and two available half-height
drive bays.
Removable Media Panel
The removable media panel must be removed to access the removable media area. To remove
the removable media panel:
1. Remove the four T-15 screws securing the removable media panel to the drive
cage assembly.
2. Pull the removable media panel away from the drive cage assembly.
Figure 2-21. Removing the removable media panel
Reverse steps 1 and 2 to replace the removable media panel.
NOTE: Ultra2 drive cage is shown.
