2-24 Removal and Replacement Procedures
Ultra2 Hot-Plug Hard Drives
Compaq ProLiant 3000 Servers may ship with Ultra2 hot-plug hard drives. Ultra2 hot-plug hard
drives are removed for replacement or for upgrade to a larger drive.
CAUTION: Do not remove a hot-plug drive if any of the online LEDs are green.
To remove an Ultra2 hot-plug hard drive:
1. Open the front bezel door (tower model only).
2. Press the release tab
1
and open the locking lever
2
that holds the drive in place.
3. Pull the drive from the cage.
1
2
Figure 2-20. Removing an Ultra2 hot-plug hard drive
Reverse steps 1 through 3 to replace an Ultra2 hot-plug hard drive.
