2-10 Removal and Replacement Procedures
Top Access Panel
WARNING: To reduce the risk of personal injury from hot surfaces, allow the
internal system components to cool before touching them.
To remove the top access panel (tower model only):
1. Perform the preparation procedures. See “Preparation Procedures” earlier in this chapter.
2. Open the front bezel door.
3. Remove the T-15 screw securing the top access panel to the front of the chassis.
4. Slide the top access panel back, then lift it from the chassis.
Figure 2-6. Removing the top access panel
Reverse steps 1 through 4 to replace the top access panel.
