Compaq ProLiant 3000 User Manual

5-2 Physical and Operating Specifications
System Unit
Table 5-1
System Unit Specifications
U.S. Metric
Dimensions
Height 20.5 in 52.1 cm
Depth 24.5 in 62.2 cm
Width 12.7 in 32.3 cm
Weight (Model 1, U.S.) 75 lbs 34 kg
Input Requirements Low range High range
Rated Input Voltage 100 to 120 V 200 to 240 V
Rated Input Frequency 50 to 60 Hz 50 to 60 Hz
Rated Input Current 8 A 6 A
Power Supply Output Power Low range High range
Rated Steady-State Power 500 W 750 W
Maximum Peak Power 540 W 780 W
Temperature Range
Operating 50° to 95°F10° to 35°C
Non-operating -20° to 140°F -30° to 60°C
Relative Humidity (noncondensing)
Operating 20% to 80% 20% to 80%
Nonoperating 5% to 90% 5% to 90%
Maximum Wet Bulb Temperature 101.7°F 38.7°C
Heat Dissipation 2594 BTU/h 3754 BTU/h
