Compaq ProLiant 3000 User Manual

5-7
Compaq ProLiant 3000 Servers, for use with Intel 350 MHz or greater processor-based servers only, Maintenance and Service Guide
IDE CD-ROM Drive Specifications Continued
U.S. Metric
Laser Parameters
Type Semiconductor laser GaAlAs
Wave Length 780 +/- 25 nm
Divergence Angle 53.5 +/- 1.5 degrees
Output Power 0.14 mW
Audio Interface
Line Out Connector
RMS Output Voltage .07 VRMs
S/N Ratio 80 dB
Channel Separation 65 dB
THD and Noise .01% @ 1kHz
Frequency Response 20 to 20 kHz, (+1/-3 dB)
Digital Audio Out Connector
2 pin digital audio out connector described in the ARAPI Spec., 2.6, Section 11.1 included. This serial digital audio out
conforms to the IEC-958 EIAJ CP-1201 format.

Compaq ProLiant 3000 Specifications

General

Brand	Compaq
Model	ProLiant 3000
Category	Server
Language	English
