2-31
Compaq ProLiant 3000 Servers, for use with Intel 350 MHz or greater processor-based servers only, Maintenance and Service Guide
Any combination of SDRAM DIMMs can be used as long as the guidelines explained earlier are
followed. Examples of possible SDRAM DIMM upgrade combinations are shown below.
Table 2-2
Examples of SDRAM DIMM Upgrade Combinations
Total
Memory Socket 1 Socket 2 Socket 3 Socket 4 Socket 5 Socket 6 Socket 7 Socket 8
128 MB 64 MB 64 MB
128 MB 128 MB
256 MB 128 MB 128 MB
256MB 32 MB 32 MB 32 MB 32 MB 32 MB 32 MB 32 MB 32 MB
512 MB 256 MB 256 MB
512 MB 128 MB 128 MB 128 MB 128 MB
1GB 256 MB 256 MB 256 MB 256 MB
1 GB 512 MB 512 MB
2 GB 256 MB 256 MB 256 MB 256 MB 256 MB 256 MB 256 MB 256 MB
2 GB 512 MB 512 MB 512 MB 512 MB
3 GB 256 MB 256 MB 512 MB 512 MB 256 MB 256 MB 512 MB 512 MB
4 GB 512 MB 512 MB 512 MB 512 MB 512 MB 512 MB 512 MB 512 MB
