3-33
Compaq ProLiant 3000 Servers, for use with Intel 350 MHz or greater processor-based servers only, Maintenance and Service Guide
Server Manager/R Board Test Error Codes
Continued
Error Code Description Recommended Action
7000-25
7000-26
7000-27
7000-28
7000-33
7000-34
7000-35
7000-41
7000-42
7000-43
7000-44
7000-45
7000-46
Memory Increment.
Memory Random Data.
Memory Disturb Address.
Memory HBM.
HBM IO.
HBM BMIC.
HBM Video.
ser_int.
ser_int.
ser_ext.
ser_ext.
ser_ext_int.
ser_ext_int.
Replace the Server Manager/R board and retest.
7000-51
7000-52
7000-53
7000-54
7000-55
7000-56
7000-57
mdm_int.
mdm_int.
mdm_ext.
mdm_ext.
mdm_ext_int.
mdm_ext_int.
mdm\c\analog.
Replace the Server Manager/R board Enhanced
2400-Baud Integrated Modem and retest.
7000-61
7000-62
Voice/DTMF Internal Loopback.
Voice/DTMF Internal Loopback.
Replace the Server Manager/R board Voice ROM.
7000-78
7000-79
Host ADC Measurements.
Battery.
Replace the Server Manager/R board battery.
