Comtech EF Data CDM-570L - Figure 2-1. Installation of the Optional Mounting Bracket

CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Installation MN/CDM570L.IOM
Equipment
Rack
Mounting
Rail
#10 Shoulder Screw
BRACKET
BOLTS
Support
Bracket
Back of Modem
Bracket
#10 Split Washer
#10 Flat Washer
#10 Flat Washer
#10 Hex Nut
Figure 2-1. Installation of the Optional Mounting Bracket
2–3
