D.3.3 Setting IP Address(es)
Step Description
1
From the Main Menu select Network Interface Configuration sub-menu [I].
2
From the Interface Configuration Menu select Ethernet Interface (fei0) sub-menu [E].
3
Set Ethernet IP Address [I].
CDM-IP 1 to 172.16.10.1
CDM-IP 2 to 172.17.10.1
4
Set Ethernet Subnet MaskSubnet Prefix Length [M] to 24.
D.3.4 Set IP Stack DES Select Key to ClearRoute Table
Perform the following steps on CDM-IP 1
Step Description
1
From Transmitter Configuration Main Menu sub-menu select Route Table [R]sub-
menu.
2
Enter 1 to configure the first route.
3
Enter a suitable name.
4
Set IP Address to 172.17.10.0
5
Set Number of Subnet Bits to 24.
6
For Interface to which route is destined to <E-Ethernet S-Satellite Enter : S>
select S.
6
For HDLC address [SMALL NETWORK] in hex <0x1 - 0xFE, enter = 0000>:
select 2.
7
CDM-IP 1 Route Table should display the following:
Route Name Dest IP/SNet Bits Next Hop MultiCast State
Route001..[test 172.17.10.0/24 0x2 N/A toSat]
Perform the following steps on CDM-IP 2
Step Description
8
From Transmitter Configuration Main Menu sub-menu select Route Table [R] sub-
menu.
9
Enter 1 to configure the first route.
10
Enter a suitable name
11
Set IP Address to 172.16.10.0
12
Set Number of Subnet Bits to 24
13
For Interface to which route is destined to <E-Ethernet S-Satellite Enter : S>
select S
