17.2.8 Configuration Page
The Configuration page is activated by selecting Configuration from the Satellite Modem
page.
The Modem Parameters page contains the following options/fields:
Menu Options/Fields Entry Description
Modem Type Read
Only
Modem type – CDM-570/570L .
Activates Tx Configuration page. Tx Configuration
T
Activates Rx Configuration page. Rx Configuration
R
Activates Framing Mode Configuration page. Framing Mode Configuration
F
Activates Data Interface Configuration page. Data Interface Configuration
I
Activates Reference Configuration page. Reference Configuration
E
Activates Alarm Mask Configuration page. Alarm Mask Configuration
A
Activates Block Up Converter (BUC) Configuration
page.
BUC Configuration
B
Activates Low Noise Block Converter (LNB)
Configuration page.
LNB Configuration
N
This option allows a user to save the current
configuration to permanent storage. This
configuration will be restored on each successive
power cycle.
Save Parameters
S
This option allows a user to exit the current menu
and return to its parent menu.
Exit
X
