Comtech EF Data CDM-570L - Figure 7-4. Comtech EF Data Turbo Product Codec Rate 3;4 QPSK;OQPSK, 8-PSK and 16-QAM

CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Forward Error Correction Options MN/CDM570L.IOM
1E-9
1E-8
1E-7
1E-6
1E-5
1E-4
1E-3
1E-2
1E-1
1 2 3 4 5 6 7 8 9 10 11 12
Eb/No in dB
Uncoded
BPSK/QPSK
Comtech Turbo Product Codec
Rate 3/4 QPSK/OQPSK,
8-PSK and 16-QAM
1 2 3 4 5 6 7 8 9 10 11 12
BER
Spec limit
Rate 3/4
16-QAM
Spec limit
Rate 3/4
8-PSK
Spec limit
Rate 3/4
QPSK/OQPSK
Typical performance
Uncoded
8-PSK
Uncoded
16-QAM
Figure 7-4. Comtech EF Data Turbo Product Codec
Rate 3/4 QPSK/OQPSK, 8-PSK AND 16-QAM
7–13
