Comtech EF Data CDM-570L - UTIL) ID (Circuit ID); UTIL) 1:1 (Manual 1:1 Switchover); UTIL) VFD (VFD Display Brightness)

CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Front Panel Operation MN/CDM570L.IOM
6–61
6.18.4 (UTIL) ID (Circuit ID)
Edit the Circuit ID string, using the
◄ ► and ▲ ▼ arrow keys. Only the bottom line is
available (24 characters). The cursor selects the position on the bottom line (
◄ ►) and
the character is then edited (
▲ ▼). The following characters are available:
Space ( ) * + - , . / 0-9 and A-Z.
When the user has composed the string, press ENTER.
6.18.5 (UTIL) 1:1 (Manual 1:1 switchover)
If the unit is part of a 1:1 redundant pair of modems, and this unit, is currently on-line,
pressing ENTER will cause the unit to switch to standby. Pressing CLEAR will exit the
menu without causing the switchover.
6.18.6 (UTIL) VFD (VFD Display brightness)
Edit the display brightness, using the ▲ ▼ arrow keys. The user should then press
ENTER.
Edit Display Brightness:
100% (▲ ▼,ENTER)
Edit Circuit ID:(◄ ►,▲ ▼)
24 CHARACTER TST MESSAGE
Press ENT to force modem
to Standby (1:1 ONLY)
