6.16.10 (INFO) ID (Circuit ID)
This displays the user-defined Circuit ID string, which is entered via the UTIL, ID
screen. To return to the previous menu, press ENTER.
6.16.11 (INFO) 1:1 (1:1 Redundancy information)
This screen shows the following:
Redundancy status - either Online or Standby (1:1 or 1:N)
1:1 link status - this shows the status of the serial link between the two units –either
Active or Idle.
Pressing ENTER or CLEAR takes the user back to the previous menu.
6.17 SAVE/LOAD
Select Save or Load using the
◄ ► arrow keys, then press ENTER.
These sub-menus permit the user to store or load up to 10 different modem configurations
in the non-volatile memory of the modem (0 through 9).
6.17.1 (SAVE/LOAD) SAVE
Selecting Save will display the following screen, if the selected location is empty:
However, if the location already contains data, the following screen will be displayed:
Save/Load Configuration:
Save Load (◄ ►,ENTER)
Save Config to Loc: 9
Empty (▲ ▼)
Redundancy State:Standby
Serial 1:1 Link: Active
Circuit ID: (ENTER)
24 CHARACTER TST MESSAGE
