CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Ethernet Management (Base Modem) MN/CDM570L.IOM
14.4 SNMP Interface
The Simple Network Management Protocol (SNMP) is an application-layer protocol
designed to facilitate the exchange of management information between network devices.
The CDM-570/570L SNMP agent supports both SNMPv1 and v2c.
IMPORTANT
For proper SNMP operation, the CDM-570/570L MIB files must be used with the
associated version of the CDM-570/570L base modem M&C. Please refer to the
CDM-570/570L SW Release Notes for information on the required FW/SW
compatibility.
14.4.1 Management Information Base (MIB) Files
MIB files are used for SNMP remote management and consist of Object Identifiers
(OID’s). Each OID is a node that provides remote management of a particular function. A
MIB file is a tree of nodes that is unique to a particular device.
There are five MIB files associated with the CDM-570:
There are five MIB files associated with the CDM-570L:
MIB File/Name Description
fw10874-2-.mib
ComtechEFData
MIB file
ComtechEFData MIB file gives the root tree for ALL Comtech EF Data
products and consists of only the following OID:
Name: comtechEFData
Type: MODULE-IDENTITY
OID: 1.3.6.1.4.1.6247
Full
path: iso(1).org(3).dod(6).internet(1).private(4).enterprises(1).comtechEFD
ata(6247)
Module: ComtechEFData
fw10874-4c .mib
CDM-570/570L
MIB file
MIB file consists of all of the OID’s for management of the modem functions
fw10874-5a .mib
CDM-570/570L
Traps MIB file
Trap MIB file is provided for SNMPv1 traps common for base modems.
Fw/10874-6a.mib
CDM-570L
BUC/LNB MIB
file
Provided for management of the CDM-570L BUC and LNB.
Fw/10874-7-.mib
CDM-570L
BUC/LNB
Traps M2B file
Trap MIB file is provided for SNMPv1 traps unique to CDM-570L.
Fw/10874-8-.mib
CSAT-5060
MIB file
MIB file consists of all the OIDs for management of the CSAT-5060
Transceiver connected to the CDM-570 modem through FSK.
Fw/10874-8-.mib
KST-2000A/B
MIB file
MIB file consists of all the OIDs for management of the KST-2000A/B
Transceiver connected to the CDM-570 modem through FSK.
