CDM-570/570L Satellite Modem with Optional IP Module Revision 4
Front Panel Operation MN/CDM570L.IOM
6–55
6.16.7 (INFO) REMCONT (Remote Control information)
This screen shows if the unit is in Local or Remote mode, and gives details of the
electrical interface type selected, the unit’s address, and the baud rate selected, etc.
Pressing ENTER or CLEAR takes the user back to the previous menu. Example:
Further examples:
6.16.8 (INFO) MASK (Alarm mask information)
This shows, in the same format as the CONFIG, Mask sub menu, which alarms are
currently masked. If an alarm is not masked, a blank is displayed in the relevant screen
position.
6.16.9 (INFO) REF (Frequency Reference)
This shows the source of the frequency reference for the CDM-570/570L.
Remote M&C: RS485-4Wire
Address: 0001 19200 Baud
Mask: FIFO BPV TAIS RAIS
AGC EbNo BUF Ref BUC LNB
Remote M&C: 100BaseTx
IP Addr: 255.255.255.255
Remote M&C: Monitor Only
(Local Control only)
Frequency Reference:
Internal 10 MHz (ENTER)
